dB Technologies Sub 915

Technical Data

• Speaker Type: Active Subwoofer

Acoustical data

• Frequency Response [-10dB]: 42 to cut frequency (Xover dependent)
• Max SPL (1 m): 133 dB
• LF: 15"
• LF Voice Coil: 4"

Amplifier

• Amp Technology: Digipro G3
• Amp Class: Class D
• Peak Power: 1800 W

Processor

• Controller: 28/56 bit DSP
• AD/DA Converter: 24 bit/48 Hz
• Limiter: Peak, Thermal, RMS
• Crossover Frequency: Variable (70Hz - 80Hz - 90 Hz - 100Hz - 110 Hz

Controls

• 1x Subwoofer Atteniation Control
• 1x Delay Rotary
• 1xXover Rotary
• 1x Polarity Switch

Input

• Signal Input: 1x XLR female, 1x USB (data service)
• Signal Output: 2x XLR male

Mechanics

• Housing: Plywood
• Handles: 2 (1x side)
• Pole Mount: 2x M20 (1 on top + 1 on side)
• Width: 620 mm
• Height: 457 mm
• Depth: 620 mm
• Weight: 34.8 kg
